What Are Construction Adhesives? Types, Bead Sizes and How Far a Cartridge Goes
A construction adhesive is a gap-filling adhesive sold in a cartridge and applied with a skeleton gun, made to stick building materials to each other on site: sheet flooring to joists, skirting to plaster, plasterboard to masonry, trims, panels and insulation boards. It is thicker than a wood glue, tolerates rough and slightly uneven surfaces, and grabs quickly enough to hold a part while it cures. This guide covers the main types, where each belongs, and then the question people actually arrive with: how many cartridges to buy. The figures come from the Coverage per Cartridge Calculator and the Adhesive Coverage Calculator.
The five families you will meet on the shelf
Labels such as "grab adhesive", "panel adhesive" and "no more nails" describe the job, not the chemistry. The chemistry is what decides where a product works, how it cures and what precautions it needs, so look for it in the small print or on the data sheet.
| Type | How it sets | Good for | Watch for |
|---|---|---|---|
| Water-based acrylic (most "grab" adhesives) | Water evaporates or soaks into the substrate | Interior trims, skirting, coving, light panels | At least one surface must be porous; slow or weak in cold, damp rooms; not for wet areas |
| Solvent-based rubber | Solvent evaporates | Fast grab on timber, metal and many plastics; tolerant of cold | Flammable vapour; attacks polystyrene; needs ventilation |
| Polyurethane (PU) | Reacts with moisture in the air and the substrate | Subfloors, exterior timber, masonry; strong and water resistant | Contains isocyanates; foams slightly; stains skin; needs clamping or fixing while it cures |
| MS polymer or hybrid ("sealant adhesive") | Reacts with moisture | Mixed materials, damp surfaces, joints that move; stays flexible | Cures from the outside in, a few millimetres a day; lower stiffness than PU |
| Two-part epoxy or resin anchor | Two components react when mixed | Fixing studs and rebar into masonry, rigid high-load bonds | Skin sensitiser; mix ratio and cure time matter; engineered fixings need the maker's design data |
Two practical rules follow from the table. First, an evaporating adhesive needs somewhere for the water or solvent to go, so bonding two non-porous surfaces (glazed tile to metal, say) with a water-based grab adhesive can leave it wet in the middle for weeks. Second, a moisture-curing adhesive needs moisture: in very dry, cold conditions a thick bead of PU or hybrid cures slowly from the skin inwards.
Bead size is the number that sets the bill
The amount of adhesive in a bead depends on the square of its diameter. That is why the nozzle cut matters more than anything else you decide at the merchant's counter. Cut the nozzle for a 6 mm bead and a standard 290 ml cartridge runs 10.26 m. Cut it for 8 mm and the same cartridge runs 5.77 m. At 10 mm it is down to 3.69 m.
| Bead diameter | 290 ml cartridge | 310 ml cartridge |
|---|---|---|
| 6 mm | 10.26 m | 10.96 m |
| 8 mm | 5.77 m | 6.17 m |
| 10 mm | 3.69 m | 3.95 m |
These are the calculator's geometric figures for a round bead with nothing left in the nozzle. Going from 6 mm to 8 mm sounds like a small change and uses 1.78 times the adhesive. Most data sheets state the bead size the product was tested with; use that, not the widest cut the nozzle allows. For a fuller table across cartridge sizes see how many metres of bead you get from a cartridge.
Worked example: gluing a chipboard subfloor
Take a room 4.0 m by 3.6 m with joists at 400 mm centres spanning the 3.6 m direction. Flooring-grade chipboard is normally glued along every joist as well as screwed, which stops the boards creaking as the timber moves.
- Count the joists. 4.0 m at 400 mm centres is 11 joists including both ends.
- Add up the run. 11 joists of 3.6 m is 39.6 m of bead.
- Turn the run into a volume. In the Adhesive Coverage Calculator, choose "Round bead diameter + length", enter 6 mm and 39.6 m. The answer is 1,120 ml.
- Divide by the cartridge. 1,120 ml is 3.9 cartridges of 290 ml, so 4 on paper.
- Allow for waste. With ten percent added for nozzle ends, starts and stops, the count becomes 5.
Now repeat it with the nozzle cut one size larger. An 8 mm bead over the same 39.6 m takes 1,991 ml, which is 8 cartridges with the same waste allowance. Nothing about the floor changed; only the cut did. The tongue-and-groove joints between boards usually want their own adhesive as well (often a D4 PVA run into the groove), and that is a separate quantity the bead figure above does not include.
Worked example: skirting board
A room with 18 m of skirting, two 6 mm beads along the back of each board, is 36 m of bead. The calculator gives 1,018 ml, so 4 cartridges of 290 ml. If the wall is true and the board is flat, a single wavy bead often does the same job with half the adhesive, but follow the data sheet: some products specify the bead pattern.
When the adhesive is spread, not beaded
Some panel and insulation-board adhesives are combed out with a notched trowel. Then thickness sets the coverage, not diameter. Switch the Coverage per Cartridge Calculator to "Area at a spread thickness": a 290 ml cartridge covers 0.145 m² at an average of 2 mm and 0.29 m² at 1 mm. A notched trowel leaves ridges and gaps, so the average thickness is roughly half the notch depth; the data sheet's coverage rate per square metre is the better guide when it gives one.
What the calculators do not cover
- They assume a round bead. A V-cut nozzle lays a triangular bead with less adhesive in it than a round bead of the same width.
- They are pure geometry. Adhesive left in the nozzle and the cartridge, absorption into rough timber or blockwork, and beads laid thick over a hollow all reduce real coverage.
- They say nothing about whether a product suits the materials, the temperature or the moisture on your job. That is on the technical data sheet.
- They do not size a structural connection. See the note below.
Surface preparation in three lines
Surfaces need to be clean, sound and free of dust, grease, loose paint and frost. Most products have a minimum application temperature, often around 5 °C, and a maximum time between running the bead and closing the joint (the open time); on a warm day that can be only a few minutes. Press the parts together firmly enough to flatten the bead, and fix or prop them until the adhesive has set. If cure time matters to your programme, the Cure Time Calculator shows how much a cold room stretches it for adhesives that cure by chemical reaction.
Safety and limits
Read the Safety Data Sheet (SDS) for the exact product before you open it. Polyurethane construction adhesives contain isocyanates, which can cause asthma and skin allergy: use them with good ventilation and keep them off your skin. Solvent-based adhesives give off flammable vapour that is heavier than air, so no naked flames, pilot lights or sparks, and keep the room ventilated until the smell has gone. Epoxy and resin anchors are skin sensitisers. Wear nitrile gloves and eye protection for all of them, and clean skin with soap and water or a proper hand cleaner, never with solvent.
A construction adhesive is not a structural fixing on its own. On floors, stairs, balustrades, cladding, anything overhead and anything that carries load, it works alongside the screws, nails or anchors the manufacturer and the building regulations require; it does not replace them. Bonded anchors and structural timber joints need the manufacturer's tested design values and a qualified engineer, not a bead calculator. Where the data sheet's coverage, bead size or cure time differs from an estimate here, the data sheet is right.
A short buying checklist
- Identify the chemistry, then check it suits both materials and the conditions (porous or not, indoors or out, wet or dry).
- Find the bead size on the data sheet and cut the nozzle to match.
- Measure the total run in metres, or the area for a spread adhesive.
- Run the numbers, add about ten percent, and round up to whole cartridges.
- Check the application temperature and the open time against the day you plan to work.
- Read the SDS and have gloves, eye protection and ventilation sorted before the first bead.
